Tokamak edge physics and recycling asymmetries concerns the coupled behavior of plasma transport, neutral recycling, and divertor asymmetry in the boundary region of magnetically confined fusion plasmas. In tokamaks, the outermost plasma layer — the scrape-off layer (SOL) — connects the confined plasma to plasma-facing components and governs how particles and heat are exhausted to the divertor.^[1]^[2]

The SOL contains open magnetic field lines that guide plasma toward divertor targets, where ions are neutralized and recycled back into the plasma as neutrals. Because cross-field drifts, parallel flows, geometry, and plasma rotation are all important in this region, the resulting neutral and particle distributions are often strongly asymmetric between the inboard high-field side (HFS) and outboard low-field side (LFS).^[3]^[4]

Abstract

Coupled fluid-kinetic simulations for high-confinement DIII-D plasmas show that plasma rotation and edge drifts jointly play a major role in shaping the poloidal distribution of recycling neutrals.^[5]^[6]

When either effect is included by itself, the calculated asymmetry is enhanced only moderately. When both are included simultaneously, however, the inboard–outboard difference becomes much stronger, in substantially better agreement with experimentally observed Lyman- $α$ emission patterns and divertor fueling asymmetries in DIII-D.^[5]^[7]^[8]

The main physical mechanism is not drift transport alone, but the way in which drifts and core-driven rotation alter parallel SOL flow and radial momentum transport, increasing deuterium flux toward the inner divertor and reducing it at the outer divertor under favorable drift orientation.^[5]

Edge plasma structure

The tokamak boundary consists of several coupled regions:

core plasma
edge pedestal
scrape-off layer (SOL)
divertor legs and divertor targets

The separatrix marks the boundary between closed magnetic field lines and open field lines. Once particles cross the separatrix, they enter the SOL and stream rapidly along the magnetic field toward plasma-facing surfaces.^[1]^[3]

Because the magnetic field, connection length, cross-field transport, and neutral source distribution are not poloidally uniform, the inner and outer divertor legs often behave differently. Such asymmetries are a standard feature of tokamak edge physics and are sensitive to magnetic configuration and drift direction.^[2]^[9]

Drift physics

Charged particles in tokamaks experience several systematic drifts, including $𝐄 \times 𝐁$ drift and magnetic-gradient/curvature drifts. In diverted plasmas, the direction of ion $𝐁 \times \nabla B$ drift relative to the X-point strongly affects where particles, momentum, and radiation accumulate in the divertor region.^[10]^[9]

Modeling and experiment both show that favorable drift orientation can substantially increase plasma density and particle flux in one divertor leg relative to the other, reversing when the field configuration is changed.^[9]^[11]

Plasma rotation

Tokamak plasmas commonly exhibit toroidal rotation, driven by mechanisms such as neutral beam injection and intrinsic momentum transport. This rotation is not confined to the core: via viscous coupling and radial momentum transport, part of the momentum reaches the edge and modifies SOL parallel flow patterns.^[5]^[12]

This is important because parallel flow, rather than local drift alone, can dominate the final redistribution of particles reaching the divertor entrance and targets.^[5]

Momentum transport

The radial transport of parallel ion momentum may be written schematically as

$Γ_{i, r}^{m} = m_{i} V_{∥ i} Γ_{i, r} - m_{i} n_{i} ν_{i}^{visc} \frac{\partial V_{∥ i}}{\partial r}$

where $V_{∥ i}$ is the parallel ion velocity, $n_{i}$ is the ion density, and $ν_{i}^{visc}$ is an effective viscosity.^[5]

This form makes clear that edge flows depend not only on particle transport but also on viscous momentum coupling between neighboring flux surfaces. In the 2025 DIII-D study, enhanced radial momentum transport was the key link through which rotation strengthened the recycling asymmetry.^[5]

Neutral recycling and Lyman- $α$ diagnostics

At the divertor targets and nearby walls, ions are neutralized and re-emitted as neutrals. These recycled neutrals can penetrate back into the plasma edge, become ionized, and thereby influence fueling, edge density buildup, and emission structure.^[1]^[2]

In DIII-D, absolutely calibrated Lyman- $α$ diagnostics such as LLAMA have made it possible to infer neutral density and ionization-rate profiles with good spatial resolution, providing a direct constraint on edge transport models.^[7]^[8]^[13]

These diagnostics are especially important because the inboard–outboard asymmetry discussed in divertor studies is often diagnosed through strongly asymmetric Lyman- $α$ emission patterns.^[5]^[13]

Combined drift and rotation effects

The central result of recent work is that drift effects and plasma rotation interact nonlinearly. Drifts reshape cross-field transport and divertor balance, while rotation modifies the parallel momentum budget and therefore the poloidal projection of SOL flow.^[5]

When both effects are retained in coupled fluid-kinetic simulations, the inboard divertor receives a substantially larger fraction of the deuterium particle flux than in cases with drift-only or rotation-only physics. This resolves much of the mismatch between earlier simulations and DIII-D measurements.^[5]^[11]

Physical interpretation

The asymmetry is best understood as a consequence of the full edge flow structure rather than as a simple local drift effect. Important ingredients include

drift-driven redistribution across the SOL
momentum coupling between core and edge
modified parallel flows into the divertor
changes in recycling-neutral source localization

Under favorable ion $𝐁 \times \nabla B$ direction, these processes reinforce one another and enhance transport toward the inner divertor target.^[5]^[10]

Significance for fusion reactors

Tokamak reactors require reliable control of divertor heat loads, particle exhaust, impurity screening, and plasma-wall interaction. Since all of these depend sensitively on SOL and divertor physics, realistic reactor modeling must include not only geometry and atomic physics, but also drifts, kinetic corrections, and momentum transport effects.^[2]^[1]

For this reason, edge asymmetries are not merely a diagnostic curiosity: they are central to divertor design, detachment control, wall lifetime, and the predictive capability needed for ITER-class and DEMO-class fusion devices.^[2]^[4]
